Leírás és Paraméterek
Processor:
- Supported processor sockets: Socket AM4
- Maximum number of SMP processors: 1
- Processor manufacturer: AMD
- Processor socket: Socket AM4
- Compatible processor series: 3rd Generation AMD Ryzen™ 9, 3rd Generation AMD Ryzen 5, 3rd Generation AMD Ryzen™ 3, 3rd Generation AMD Ryzen™ 7
Features:
- Audio output channels: 7.1 channels
- Motherboard form factor: ATX
- Motherboard chipset: AMD B550
- Audio chip: Realtek ALC S1200A
- Windows operating systems supported: Windows 10 x64
- Motherboard chipset family: AMD
Memory:
- Supported memory clock speeds: 3600, 3333, 4600, 3200, 2666, 4266, 2133, 4133, 4000, 3000, 3733, 4400, 2400, 2800, 3866, 3466
- Maximum internal memory: 128 GB
- Memory channels: Dual-channel
- Number of memory slots: 4
- Supported memory types: DDR4-SDRAM
- Memory slots type: DIMM
Weight & dimensions:
- Depth: 244 mm
- Width: 305 mm
Network:
- LAN controller: Realtek RTL8125B
- Wi-Fi: No
- Ethernet LAN: Yes
- Ethernet interface type: 2.5 Gigabit Ethernet
Internal I/O:
- Number of SATA connectors: 4
- USB 2.0 connectors: 2
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- Number of chassis fan connectors: 3
- ATX Power connector (24-pin): Yes
- Front panel audio connector: Yes
- EPS power connector (8-pin): Yes
- Number of SATA III connectors: 6
- CPU fan connector: Yes
- TPM connector: Yes
BIOS:
- BIOS type: UEFI AMI
- Clear CMOS jumper: Yes
Packaging content:
- Cables included: SATA
- Drivers included: Yes
Storage controllers:
- Supported storage drive interfaces: M.2, Serial ATA
- RAID levels: 10, 0, 1
Rear panel I/O ports:
- DisplayPorts quantity: 1
- S/PDIF out port: Yes
- Ethernet LAN (RJ-45) ports: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
- USB 2.0 ports quantity: 2
- HDMI ports quantity: 1
- PS/2 ports quantity: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
Expansion slots:
- Number of M.2 (M) slots: 2
- PCI Express x1 (Gen 3.x) slots: 3
- PCI Express x16 (Gen 3.x) slots: 1
- PCI Express x16 (Gen 4.x) slots: 1
