Leírás és Paraméterek
Processor:
- Processor socket: Socket AM5
- Processor manufacturer: AMD
- Supported processor sockets: Socket AM5
Graphics:
- Parallel processing technology support: Not supported
- On-board graphics card: No
Features:
- Audio output channels: 7.1 channels
- Motherboard chipset family: AMD
- Windows operating systems supported: Windows 11, Windows 10 x64
- Product colour: Black
- Motherboard form factor: ATX
- Motherboard chipset: AMD B650
Memory:
- Supported memory clock speeds: 6600, 5800, 5400, 6000, 6400, 5000, 5600, 7200, 7000, 7600, 7800, 6200, 5200, 8000, 6800, 4800
- Number of memory slots: 4
- ECC сompatibility: ECC & Non-ECC
- Supported memory clock speed (max): 8000 MHz
- Unbuffered memory: Yes
- Memory slots type: DIMM
- Supported memory types: DDR5-SDRAM
- Memory channels: Dual-channel
- Maximum internal memory: 192 GB
Weight & dimensions:
- Depth: 244 mm
- Width: 305 mm
Network:
- Wi-Fi standards: 802.11g, 802.11b, Wi-Fi 6E (802.11ax), Wi-Fi 4 (802.11n), 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac)
- Ethernet LAN: Yes
- Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
- Bluetooth version: 5.3
- Wi-Fi: Yes
- Ethernet interface type: 2.5 Gigabit Ethernet
- Bluetooth: Yes
Internal I/O:
- CPU fan connector: Yes
- Number of SATA III connectors: 4
- USB 2.0 connectors: 2
- Peripheral (Molex) power connectors (4-pin): 1
- Front panel audio connector: Yes
- ATX Power connector (24-pin): Yes
- Number of COM connectors: 1
- RGB LED pin header: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- EPS power connector (8-pin): Yes
- Number of chassis fan connectors: 4
- 12V power connector: Yes
- USB 3.2 Gen 2x2 connectors: 1
Packaging data:
- Package weight: 1.36 kg
- Package width: 338 mm
- Package height: 68 mm
- Package depth: 273 mm
Storage controllers:
- RAID levels: 0, 1, 10
- Supported storage drive types: HDD & SSD
- RAID support: Yes
- Number of HDDs supported: 4
- Number of storage drives supported: 7
- Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports:
- DisplayPorts quantity: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
- Ethernet LAN (RJ-45) ports: 1
- HDMI ports quantity: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
- WiFi-AP antenna jack: 1
- Microphone in: Yes
- USB 2.0 ports quantity: 3
Expansion slots:
- PCI Express x1 (Gen 4.x) slots: 1
- Number of M.2 (M) slots: 3
- PCI Express x16 (Gen 4.x) slots: 3
