Leírás és Paraméterek
Processor:
- Supported processor sockets: Socket AM5
- Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
- Processor socket: Socket AM5
- Processor manufacturer: AMD
Graphics:
- Maximum resolution: 3840 x 2160 pixels
- Parallel processing technology support: Not supported
Features:
- Motherboard form factor: ATX
- Motherboard chipset: AMD X870
- Motherboard chipset family: AMD
- Product colour: White
- Audio output channels: 7.1 channels
- Windows operating systems supported: Windows 11
Memory:
- Supported memory clock speed (max): 8000 MHz
- ECC сompatibility: ECC & Non-ECC
- Unbuffered memory: Yes
- Supported memory types: DDR5-SDRAM
- Maximum internal memory: 256 GB
- Number of memory slots: 4
- Memory slots type: DIMM
- Memory channels: Dual-channel
Weight & dimensions:
- Depth: 244 mm
- Width: 305 mm
Network:
- Wake-on-LAN ready: Yes
- Bluetooth version: 5.4
- Ethernet LAN: Yes
- Bluetooth: Yes
- Top Wi-Fi standard: Wi-Fi 7 (802.11be)
- Wi-Fi: Yes
- Ethernet interface type: 2.5 Gigabit Ethernet
Internal I/O:
- USB 3.2 Gen 2x2 connectors: 1
- Number of SATA III connectors: 4
- Number of COM connectors: 1
- Number of EPS power connectors (8-pin): 2
- S/PDIF out connector: Yes
- USB 2.0 connectors: 2
- 12V power connector: Yes
- TPM connector: Yes
- Number of chassis fan connectors: 4
- Number of water pump connectors: 1
- Number of RGB LED pin headers: 3
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- Front panel audio connector: Yes
- ATX Power connector (24-pin): Yes
- EPS power connector (8-pin): Yes
- RGB LED pin header: Yes
- CPU fan connector: Yes
- Number of CPU fan connectors: 2
- Chassis intrusion connector: Yes
BIOS:
- BIOS type: UEFI AMI
- Clear CMOS jumper: Yes
Packaging content:
- Screws included: Yes
- Antenna included: Yes
- Cables included: SATA
Storage controllers:
- Supported storage drive interfaces: PCI Express 4.0, PCI Express 5.0, SATA III
- RAID levels: 1, 5, 10, 0
- Supported storage drive types: HDD & SSD
- Number of storage drives supported: 7
- RAID support: Yes
Rear panel I/O ports:
- USB4 Gen 3x2 ports quantity: 2
- USB connector type: USB Type-C, USB Type-A
- Ethernet LAN (RJ-45) ports: 1
- USB 2.0 ports quantity: 4
- Headphone outputs: 3
- WiFi-AP antenna jack: 2
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
- Microphone in: Yes
- HDMI version: 2.1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
- HDMI ports quantity: 1
Expansion slots:
- PCI Express x16 (Gen 5.x) slots: 1
- PCI Express x16 (Gen 3.x) slots: 1
- PCI Express x16 (Gen 4.x) slots: 2
- Number of M.2 (M) slots: 3
