Leírás és Paraméterek
Processor:
- Processor manufacturer: Intel
- Compatible processor series: Intel® Core™ i5, Intel® Celeron®, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold, Intel® Core™ i3
- Supported processor sockets: LGA 1700
- Processor socket: LGA 1700
Graphics:
- HDCP: Yes
- Parallel processing technology support: Not supported
- Maximum resolution: 4096 x 2304 pixels
- HDCP version: 2.3
Features:
- Audio output channels: 7.1 channels
- Windows operating systems supported: Windows 11, Windows 10
- Motherboard form factor: ATX
- PC health monitoring: Temperature, Voltage, Fan, Water cooling
- Motherboard chipset family: Intel
- Power source type: ATX
Memory:
- Supported memory clock speeds: 3200, 2666, 4266, 3400, 3866, 3800, 3333, 4600, 3733, 4300, 4400, 5000, 2933, 3600, 3300, 5133, 3000, 5333 MHz, 2133, 3466, 4500, 2400, 4700, 4133, 4000, 3666, 4800, 4933
- Maximum internal memory: 128 GB
- Memory slots type: DIMM
- Unbuffered memory: Yes
- Number of memory slots: 4
- Supported memory clock speed (max): 5333 MHz
- Memory channels: Dual-channel
- Supported memory types: DDR4-SDRAM
Weight & dimensions:
- Depth: 244 mm
- Width: 305 mm
Network:
- Ethernet LAN: Yes
- Ethernet interface type: 2.5 Gigabit Ethernet
Internal I/O:
- Front panel connector: Yes
- Number of SATA III connectors: 4
- Front panel audio connector: Yes
- ATX Power connector (24-pin): Yes
- USB 2.0 connectors: 2
- Number of chassis fan connectors: 3
- CPU fan connector: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- Serial port headers: 1
- USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
- RGB LED pin header: Yes
- S/PDIF out connector: Yes
- EPS power connector (8-pin): Yes
- TPM connector: Yes
BIOS:
- BIOS type: UEFI AMI
- Clear CMOS jumper: Yes
- Desktop Management Interface (DMI) version: 2.7
Storage controllers:
- RAID levels: 0, 1, 10, 5
- Number of storage drives supported: 6
- Supported storage drive types: HDD & SSD
- Supported storage drive interfaces: M.2, SATA III
- RAID support: Yes
Rear panel I/O ports:
- Ethernet LAN (RJ-45) ports: 1
- DisplayPorts quantity: 1
- Microphone in: Yes
- USB 2.0 ports quantity: 5
- Number of USB 3.2 Gen 2 Type-A ports: 1
- Line-in: Yes
- HDMI ports quantity: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
- Headphone outputs: 1
Expansion slots:
- PCI Express x16 (Gen 3.x) slots: 2
- Number of M.2 (M) slots: 3
- PCI Express x16 (Gen 4.x) slots: 1
