Leírás és Paraméterek
Processor:
- Compatible processor series: AMD Ryzen 7000 Series, AMD EPYC 4005, AMD EPYC 4004, AMD Ryzen 8000 Series
- Processor manufacturer: AMD
- Processor socket: Socket AM5
Graphics:
- On-board graphics card model: Aspeed AST2600 BMC
- On-board graphics card: Yes
Features:
- Motherboard chipset family: AMD
- Motherboard form factor: micro ATX
- Motherboard chipset: AMD B650
- Component for: Server
Memory:
- Maximum internal memory: 48 GB
- Supported memory clock speeds: 5200 MHz, 3600
- Number of memory slots: 4
- Memory slots type: DIMM
- Supported memory types: DDR5-SDRAM
Operational conditions:
- Storage temperature (T-T): -20 - 70 °C
- Operating temperature (T-T): 0 - 40 °C
- Operating relative humidity (H-H): 5 - 85%
Weight & dimensions:
- Depth: 243.8 mm
- Width: 243.8 mm
Internal I/O:
- Number of SATA III connectors: 4
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
- Number of chassis fan connectors: 9
- Number of COM connectors: 1
- TPM connector: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
- Power fan connector: Yes
- Number of SATA II connectors: 2
Storage controllers:
- Supported storage drive interfaces: M.2, SATA II, SATA III
- Supported storage drive types: HDD & SSD
- Number of HDDs supported: 6
- Number of storage drives supported: 8
Rear panel I/O ports:
- Ethernet LAN (RJ-45) ports: 3
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
Expansion slots:
- PCI Express x8 (Gen 4.x) slots: 1
- PCI Express x16 (Gen 5.x) slots: 1
- Number of M.2 (M) slots: 2
