Leírás és Paraméterek
Processor:
- Processor socket: LGA 1700
- Compatible processor series: Intel® Celeron®, Intel® Pentium® Gold
- Supported processor sockets: LGA 1700
- Processor manufacturer: Intel
Features:
- Motherboard form factor: ATX
- Windows operating systems supported: Windows 11 x64, Windows 10 x64
- Audio output channels: 7.1 channels
- Motherboard chipset: Intel Z790
- Motherboard chipset family: Intel
Memory:
- Unbuffered memory: Yes
- Supported memory clock speed (max): 5333 MHz
- Supported memory types: DDR5-SDRAM
- Supported memory clock speeds: 5200, 4800, 6600, 6400, 6000, 6800, 6200, 7000, 5600, 7200, 5800, 5400
- Number of memory slots: 4
- Memory channels: Dual-channel
- Maximum internal memory: 128 GB
Weight & dimensions:
- Width: 304.8 mm
- Depth: 243.8 mm
Network:
- Bluetooth version: 5.3
- Wi-Fi: Yes
- Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
- Wi-Fi standards: Wi-Fi 4 (802.11n), 802.11a, Wi-Fi 6 (802.11ax), 802.11g, Wi-Fi 5 (802.11ac), 802.11b
- Bluetooth: Yes
- Ethernet LAN: Yes
- Ethernet interface type: 2.5 Gigabit Ethernet
Internal I/O:
- RGB LED pin header: Yes
- TPM connector: Yes
- USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
- Front panel audio connector: Yes
- Front panel connector: Yes
- USB 2.0 connectors: 4
- CPU fan connector: Yes
- Number of SATA II connectors: 6
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
- Chassis intrusion connector: Yes
Storage controllers:
- RAID levels: 5, 10, 0
- Supported storage drive types: HDD & SSD
- Supported storage drive interfaces: M.2, PCI Express
- Internal storage capacity: 10 GB
Rear panel I/O ports:
- DisplayPort version: 1.4
- Ethernet LAN (RJ-45) ports: 1
- DisplayPorts quantity: 1
- HDMI version: 2.1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 4
- USB 3.2 Gen 2x2 Type-C ports quantity: 1
- S/PDIF out port: Yes
- HDMI ports quantity: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
