Processor:
- Processor manufacturer: Intel
- Compatible processor series: Intel® Celeron®, Intel® Pentium® Gold
- Supported processor sockets: LGA 1700
- Maximum number of SMP processors: 1
- Processor socket: LGA 1700
Features:
- Audio output channels: 7.1 channels
- Motherboard form factor: ATX
- Product colour: Black
- Audio chip: Realtek ALC897
- Windows operating systems supported: Windows 11, Windows 10
- Motherboard chipset family: Intel
- Power source type: ATX
Memory:
- Supported memory clock speeds: 5333 MHz, 4000, 4800, 3400, 3466, 3200, 2666, 4266, 4600, 5200, 2933, 3600, 2400, 5066, 3733, 4400 MHz, 5000, 2133, 4200, 3800, 3333
- Number of memory slots: 4
- Maximum internal memory: 128 GB
- Supported memory types: DDR4-SDRAM
- Supported memory clock speed (max): 5333 MHz
- Memory channels: Dual-channel
- ECC сompatibility: Non-ECC
- Memory slots type: DIMM
Weight & dimensions:
- Width: 243.8 mm
- Depth: 304.8 mm
Network:
- Bluetooth: Yes
- Ethernet LAN: Yes
- Wi-Fi: Yes
- Ethernet interface type: 2.5 Gigabit Ethernet
Internal I/O:
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 4
- USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
- Front panel audio connector: Yes
- CPU fan connector: Yes
- TPM connector: Yes
- Front panel connector: Yes
- Number of SATA III connectors: 4
- RGB LED pin header: Yes
- ATX Power connector (24-pin): Yes
- USB 2.0 connectors: 4
Storage controllers:
- RAID support: Yes
- RAID levels: 0, 5, 10, 1
- Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports:
- HDMI ports quantity: 1
- Ethernet LAN (RJ-45) ports: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
- USB 2.0 ports quantity: 2
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
- DisplayPorts quantity: 1
Expansion slots:
- Number of M.2 (M) slots: 2
- PCI Express x16 slots: 5
