Leírás és Paraméterek
Processor:
- Compatible processor series: Intel® Pentium® Gold, Intel® Celeron®
- Processor manufacturer: Intel
- Supported processor sockets: LGA 1700
- Maximum number of SMP processors: 1
- Processor socket: LGA 1700
Features:
- Motherboard form factor: micro ATX
- Audio chip: Realtek ALC897
- Audio output channels: 7.1 channels
- Windows operating systems supported: Windows 11, Windows 10
- Motherboard chipset family: Intel
- Motherboard chipset: Intel B760
- Power source type: ATX
Memory:
- Supported memory clock speed (max): 4800 MHz
- Memory channels: Dual-channel
- Number of memory slots: 2
- Memory slots type: DIMM
- Supported memory clock speeds: 3800, 3333, 2400, 3200, 2666, 4266, 3400, 3466, 2133, 4200, 2933, 3600, 3733, 4400, 4600, 4000, 4800
- Maximum internal memory: 64 GB
- Supported memory types: DDR4-SDRAM
- ECC сompatibility: Non-ECC
Weight & dimensions:
- Width: 220 mm
- Depth: 243.8 mm
Network:
- Ethernet LAN: Yes
- Ethernet interface type: Gigabit Ethernet
- Wi-Fi: No
Internal I/O:
- Front panel connector: Yes
- TPM connector: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- Front panel audio connector: Yes
- USB 2.0 connectors: 2
- RGB LED pin header: Yes
- CPU fan connector: Yes
- Number of SATA connectors: 4
- ATX Power connector (24-pin): Yes
Storage controllers:
- RAID levels: 0, 1, 10, 5
- Supported storage drive interfaces: M.2, SATA
- RAID support: Yes
Rear panel I/O ports:
- Ethernet LAN (RJ-45) ports: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
- HDMI version: 2.1
- VGA (D-Sub) ports quantity: 1
- HDMI ports quantity: 1
- USB 2.0 ports quantity: 4
Expansion slots:
- PCI Express x1 slots: 1
- PCI Express x16 slots: 1
