Technical details:
- Sustainability compliance: Yes
- Sustainability certificates: ErP
- Compliance certificates: Federal Communications Commission (FCC), CE, EuP
Processor:
- Processor manufacturer: Intel
- Compatible processor series: Intel® Celeron® G, Intel® Core™ i7, Intel® Core™ i9, Intel® Core™ i3, Intel® Core™ i5, Intel® Pentium® Gold
- Supported processor sockets: LGA 1700
- Processor socket: LGA 1700
Graphics:
- Graphics card: Intel Iris Xe Graphics
- Maximum resolution: 7680 x 4320 pixels
- Graphics card family: Intel
- Parallel processing technology support: Crossfire
- HDCP: Yes
Features:
- Motherboard chipset: Intel Z790
- Audio chip: Realtek ALC4082
- Audio output channels: 7.1 channels
- Windows operating systems supported: Windows 11 x64, Windows 10 x64
- Product colour: Black
- Motherboard chipset family: Intel
- Motherboard form factor: ATX
Memory:
- Unbuffered memory: Yes
- Memory channels: Dual-channel
- Maximum internal memory: 192 GB
- Memory slots type: DIMM
- Supported memory types: DDR5-SDRAM
- Supported memory clock speed (max): 8000 MHz
- Number of memory slots: 4
- ECC сompatibility: Non-ECC
Weight & dimensions:
- Width: 305 mm
- Depth: 244 mm
Network:
- Wi-Fi standards: Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), 802.11b, 802.11g, 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n)
- Top Wi-Fi standard: Wi-Fi 7 (802.11be)
- LAN controller: Killer E3100G
- Bluetooth: Yes
- Bluetooth version: 5.4
- Ethernet LAN: Yes
- Wi-Fi: Yes
- Ethernet interface type: 2.5 Gigabit Ethernet
Internal I/O:
- Thunderbolt headers: 1
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
- Number of chassis fan connectors: 5
- Number of SATA III connectors: 4
- USB 2.0 connectors: 2
- TPM connector: Yes
- ATX Power connector (24-pin): Yes
- CPU fan connector: Yes
- Front panel audio connector: Yes
- RGB LED pin header: Yes
- 12V power connector: Yes
- USB 3.2 Gen 2x2 connectors: 1
BIOS:
- BIOS type: UEFI AMI
- Clear CMOS button: Yes
Packaging content:
- Cables included: SATA
- Screws included: Yes
- Antenna included: Yes
- M.2 standoff included: Yes
Storage controllers:
- RAID levels: 5, 10, 0, 1
- Number of storage drives supported: 6
- RAID support: Yes
- Supported storage drive interfaces: M.2
Rear panel I/O ports:
- DisplayPorts quantity: 1
- USB 2.0 ports quantity: 2
- S/PDIF out port: Yes
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 4
- HDMI version: 2.1
- USB connector type: USB Type-A, USB Type-C
- DisplayPort version: 1.4
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
- Ethernet LAN (RJ-45) ports: 1
- HDMI ports quantity: 1
- Microphone in: Yes
- USB 3.2 Gen 2x2 Type-C ports quantity: 1
- WiFi-AP antenna jack: 2
Expansion slots:
- PCI Express x1 (Gen 3.x) slots: 1
- Number of M.2 (M) slots: 1
- PCI Express x16 (Gen 5.x) slots: 1
- PCI Express x16 (Gen 4.x) slots: 1
