Processor:
- Processor socket: LGA 1700
- Compatible processor series: Intel® Core™ i5, Intel® Celeron®, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold, Intel® Core™ i3
- Processor manufacturer: Intel
- Supported processor sockets: LGA 1700
Graphics:
- HDCP: Yes
- Parallel processing technology support: CrossFireX
- Maximum resolution: 4096 x 2304 pixels
Features:
- Motherboard chipset family: Intel
- Windows operating systems supported: Windows 11, Windows 10
- Power source type: ATX
- Audio output channels: 7.1 channels
- Motherboard chipset: Intel B760
- PC health monitoring: Fan, Temperature, Water cooling, Voltage
- Motherboard form factor: micro ATX
Memory:
- Supported memory types: DDR5-SDRAM
- Maximum internal memory: 128 GB
- Supported memory clock speeds: 7000, 6200, 6800, 6400, 7400, 6000, 5300, 6600, 5800, 5400, 7600, 5600, 7200, 4000, 4800
- Number of memory slots: 4
- Unbuffered memory: Yes
- Supported memory clock speed (max): 7600 MHz
- Memory slots type: DIMM
Weight & dimensions:
- Depth: 244 mm
- Width: 244 mm
Network:
- Wi-Fi standards: Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), 802.11g, 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), 802.11b
- Bluetooth version: 5.3
- Ethernet LAN: Yes
- Bluetooth: Yes
- Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
- Ethernet interface type: 2.5 Gigabit Ethernet, 5 Gigabit Ethernet
- Wi-Fi: Yes
Internal I/O:
- ATX Power connector (24-pin): Yes
- Number of chassis fan connectors: 3
- CPU fan connector: Yes
- Front panel audio connector: Yes
- Number of SATA III connectors: 4
- Peripheral (Molex) power connectors (4-pin): 1
- USB 2.0 connectors: 2
- Front panel connector: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- S/PDIF out connector: Yes
- USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
- RGB LED pin header: Yes
- EPS power connector (8-pin): Yes
- TPM connector: Yes
- Thunderbolt headers: 2
BIOS:
- Clear CMOS jumper: Yes
- Desktop Management Interface (DMI) version: 2.7
- BIOS type: UEFI AMI
Storage controllers:
- Supported storage drive types: HDD & SSD
- Number of storage drives supported: 6
- RAID levels: 1, 10, 0, 5
- Supported storage drive interfaces: M.2, SATA III
- RAID support: Yes
Rear panel I/O ports:
- Ethernet LAN (RJ-45) ports: 1
- USB 2.0 ports quantity: 4
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
- USB 3.2 Gen 2x2 Type-C ports quantity: 1
- WiFi-AP antenna jack: 2
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
- DisplayPorts quantity: 1
- Microphone in: Yes
- HDMI ports quantity: 1
- Headphone outputs: 1
Expansion slots:
- PCI Express x16 (Gen 4.x) slots: 1
- Number of M.2 (M) slots: 1
