Leírás és Paraméterek
Processor:
- Processor manufacturer: Intel
- Compatible processor series: Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium®, Intel® Core™ i3, Intel® Core™ i5, Intel® Celeron®
- Maximum number of SMP processors: 1
- Processor socket: LGA 1700
Features:
- Motherboard form factor: micro ATX
- Motherboard chipset family: Intel
- Audio output channels: 7.1 channels
- Motherboard chipset: Intel H610
- Windows operating systems supported: Windows 11 x64, Windows 10 x64
Memory:
- Maximum internal memory: 64 GB
- Supported memory clock speeds: 2400, 2800, 3200, 2666, 2133, 3000, 2933
- Unbuffered memory: Yes
- Supported memory types: DDR4-SDRAM, LPDDR3-SDRAM
- Number of memory slots: 2
- Memory slots type: DIMM
- Memory channels: Dual-channel
- ECC сompatibility: Non-ECC
Weight & dimensions:
- Height: 221 mm
- Depth: 211 mm
- Width: 244 mm
Network:
- Wake-on-LAN ready: Yes
- Ethernet interface type: Gigabit Ethernet
- Ethernet LAN: Yes
- Wi-Fi: No
Internal I/O:
- CPU fan connector: Yes
- Number of SATA III connectors: 4
- S/PDIF out connector: Yes
- USB 2.0 connectors: 1
- Front panel audio connector: Yes
- ATX Power connector (24-pin): Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- RGB LED pin header: Yes
- TPM connector: Yes
- Number of chassis fan connectors: 2
- Number of COM connectors: 1
- 12V power connector: Yes
Storage controllers:
- Supported storage drive types: HDD & SSD
- Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports:
- DisplayPorts quantity: 1
- DisplayPort version: 1.4
- USB 2.0 ports quantity: 4
- Ethernet LAN (RJ-45) ports: 1
- HDMI ports quantity: 1
- HDMI version: 2.1
- VGA (D-Sub) ports quantity: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
- PS/2 ports quantity: 2
Expansion slots:
- PCI Express x1 (Gen 3.x) slots: 1
- Number of M.2 (M) slots: 2
- PCI Express x16 (Gen 4.x) slots: 1
