Leírás és Paraméterek
Processor:
- Processor socket: Socket AM5
- Compatible processor series: AMD Ryzen™ 7
- Supported processor sockets: Socket AM5
- Processor manufacturer: AMD
Graphics:
- Parallel processing technology support: Not supported
- On-board graphics card: No
Features:
- Product colour: Black, Silver
- Motherboard chipset: AMD B650
- Audio output channels: 7.1 channels
- Motherboard form factor: ATX
- Audio chip: Realtek ALC4080
- Windows operating systems supported: Windows 11 x64
- Motherboard chipset family: AMD
Memory:
- Maximum internal memory: 128 GB
- Supported memory clock speeds: 5800, 5400, 5000, 5600, 6400, 5200, 6000, 6200, 4800
- Unbuffered memory: Yes
- Memory slots type: DIMM
- Supported memory types: DDR5-SDRAM
- Memory channels: Dual-channel
- ECC сompatibility: ECC & Non-ECC
- Number of memory slots: 4
Weight & dimensions:
- Width: 305 mm
- Depth: 244 mm
Network:
- LAN controller: Intel I225-V
- Bluetooth: Yes
- Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
- Wi-Fi standards: 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 4 (802.11n), 802.11b, Wi-Fi 5 (802.11ac), 802.11g
- Wi-Fi: Yes
- Bluetooth version: 5.2
- Ethernet LAN: Yes
- Ethernet interface type: 2.5 Gigabit Ethernet
Internal I/O:
- USB 2.0 connectors: 4
- ATX Power connector (24-pin): Yes
- S/PDIF out connector: Yes
- USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
- Number of COM connectors: 1
- Front panel audio connector: Yes
- Thunderbolt headers: 1
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
- EPS power connector (8-pin): Yes
- Number of SATA III connectors: 4
- RGB LED pin header: Yes
- 12V power connector: Yes
- CPU fan connector: Yes
- Chassis intrusion connector: Yes
- Number of chassis fan connectors: 4
- Peripheral (Molex) power connectors (4-pin): 1
BIOS:
- Clear CMOS button: Yes
- BIOS type: UEFI AMI
Packaging data:
- Package weight: 9 kg
- Package depth: 265 mm
- Package height: 71 mm
- Package width: 280 mm
Storage controllers:
- RAID levels: 10, 1, 0
- Supported storage drive types: HDD & SSD
- Supported storage drive interfaces: M.2, SATA III
- RAID support: Yes
Rear panel I/O ports:
- Microphone in: Yes
- Line-in: Yes
- Ethernet LAN (RJ-45) ports: 1
- USB 2.0 ports quantity: 4
- Headphone outputs: 3
- DisplayPorts quantity: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 3
- HDMI ports quantity: 1
Expansion slots:
- Number of M.2 (M) slots: 3
- PCI Express x16 (Gen 4.x) slots: 1
- PCI Express x16 (Gen 5.x) slots: 1
- PCI Express x1 (Gen 4.x) slots: 2
