Processor:
- Compatible processor series: AMD Ryzen 9000 Series, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series
- Processor manufacturer: AMD
- Processor socket: Socket AM5
Features:
- Motherboard chipset family: AMD
- Motherboard form factor: ATX
- Power source type: ATX
- Audio output channels: 7.1 channels
- Product colour: Black
- Audio chip: Realtek ALC897
- Motherboard chipset: AMD B850
Memory:
- Supported memory types: DDR5-SDRAM
- Memory slots type: DIMM
- Memory channels: Dual-channel
- Number of memory slots: 4
- Unbuffered memory: Yes
- Maximum internal memory: 256 GB
- ECC сompatibility: Non-ECC
Weight & dimensions:
- Width: 243.8 mm
- Depth: 304.8 mm
Network:
- LAN controller: Realtek RTL8125
- Wi-Fi standards: Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n), 802.11g, 802.11b, 802.11a, Wi-Fi 6E (802.11ax)
- Bluetooth version: 5.3
- Ethernet LAN: Yes
- Ethernet interface type: 2.5 Gigabit Ethernet
- Bluetooth: Yes
- Wi-Fi: Yes
- Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Internal I/O:
- CPU fan connector: Yes
- Number of SATA III connectors: 4
- Number of COM connectors: 1
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
- USB 2.0 connectors: 4
- Power fan connector: Yes
- Front panel connector: Yes
- Chassis intrusion connector: Yes
- Front panel audio connector: Yes
- Audio connector: Yes
- RGB LED pin header: Yes
- TPM connector: Yes
- Number of CPU fan connectors: 1
Packaging content:
- Antenna included: Yes
- Screws included: Yes
- Cables included: SATA
Storage controllers:
- RAID levels: 1, 10, 0
- Supported storage drive types: HDD & SSD
- Supported storage drive interfaces: M.2, SATA
- RAID support: Yes
Rear panel I/O ports:
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 3
- DisplayPorts quantity: 1
- Ethernet LAN (RJ-45) ports: 1
- HDMI ports quantity: 1
- HDMI version: 2.1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
- DisplayPort version: 1.4
Expansion slots:
- PCI Express x16 (Gen 4.x) slots: 1
- Number of M.2 (M) slots: 2
- PCI Express x1 (Gen 3.x) slots: 1
- 2nd M.2 highest PCI Express generation: 4.0
- 1st M.2 highest PCI Express generation: 5.0
- PCI Express x4 (Gen 4.x) slots: 1
